Distributed Human-in-the-Loop Model Predictive Control

  • Checkout

    Checkout

    Do you already own this?

    Pricing


    Individuals

    AIChE Member Credits 0.5
    AIChE Members $19.00
    AIChE Graduate Student Members Free
    AIChE Undergraduate Student Members Free
    Non-Members $29.00
  • Type:
    Conference Presentation
  • Conference Type:
    AIChE Annual Meeting
  • Presentation Date:
    November 8, 2021
  • Duration:
    19 minutes
  • Skill Level:
    Intermediate
  • PDHs:
    0.50

Share This Post:

Chemical plants are highly complicated processes that function based on complex automation and human decisions. Humans are present at every hierarchy of the process and act as decision-making agents [1 and 2]. Along with the implementation of Model Predictive Control, a coordinated decision-making phenomenon arises [3]. In the current article, the implementation of a distributed Human-in-The-Loop (HiTL) MPC is presented where each subsystem of a plant is controlled by an operator and an HiTL MPC. Considering that the HiTL MPC formulation is primarily for operator training purposes, the distributed MPC problem is crucial to allow multiple operators train on a complex plant.

In the first part, a brief discussion of the standard HiTL MPC is given as was shown in [3]. For detailed derivations readers are referred to [4]. The MPC optimization objective is to minimize the set-point change input to regulatory PID controllers by penalizing the deviation from upper-layer output setpoints and human suggested inputs. Depending on the input/output pairs chosen for manual and MPC, the state-space matrices are modified. For shared control of input/output pairs, a tuning parameter is also included to weigh the human inputs.

When the control of a plant is shared between multiple MPC it gives rise to distributed MPC formulations and the plant is also divided into subsystems. Distributed MPC comes in various architectures and detailed discussions of the theoretical and application aspects can be found in ([5] and [6]). The second part of the work discusses the distributed HiTL MPC formulations where the study is restricted to only two subsystems (e.g., only two CSTRs being controlled by two HiTL MPCs). The types of distributed MPC architectures considered are as follows. The first example discusses the decentralized HiTL MPC without mutual communications, the second example discusses a non-cooperative sequential distributed HiTL MPC (communication occurs only in one direction) and the third example discusses non-cooperative parallel distributed HiTL MPC (communication occurs in both directions). Figure 1 summarizes these formulations. The architectures pertaining to cooperative distributed MPC is out of scope for this work and is not shown here.

The examples used are two Single-Input Single-Output (SISO) CSTRs in series where the operator shares the control decision with the MPC.

Concluding remarks on advanced architectures, aspects of operator inputs and future directions are provided.

References

[1] Ghosh, S. and Bequette, B.W., 2019. Process Systems Engineering and the Human-in-The-Loop: The Smart Control Room. Industrial & Engineering Chemistry Research, 59(6), pp.2422-2429.

[2] Ghosh, S. and Bequette, B.W., 2019. A Framework for the Control Room of the Future: Human-in-the-loop MPC. IFAC-PapersOnLine, 51(34), pp.252-257.

[3] Ghosh, S. and Bequette, B.W., Human-in-the-Loop: Coordinated Decision-Making in AICHE Annual Meeting, 2020, Virtual (https://youtu.be/8NXc-hCLo9c)

[4] Ghosh, S. and Bequette, B.W., 2021. Human-in-The-Loop Model Predictive Control. Manuscript under preparation

[5] Christofides, P.D., Scattolini, R., de la Pena, D.M. and Liu, J., 2013. Distributed model predictive control: A tutorial review and future research directions. Computers & Chemical Engineering, 51, pp.21-41.

[6] Rawlings, J.B., Mayne, D.Q. and Diehl, M., 2017. Model predictive control: theory, computation, and design (Vol. 2). Madison, WI: Nob Hill Publishing.

Figure Captions

Figure 1: The architectures of distributed HiTL MPC discussed in the current work – (a) Decentralized (b) Non-cooperative series (c) Non-cooperative parallel.
