Data-Driven Identification of an Industrial Reverse Osmosis Membrane Process: Impact of the Feed Properties, Plant Variables and the Operating Window

  • Checkout

    Checkout

    Do you already own this?

    Pricing


    Individuals

    AIChE Member Credits 0.5
    AIChE Members $19.00
    AIChE Graduate Student Members Free
    AIChE Undergraduate Student Members Free
    Computing and Systems Technology Division Members Free
    Non-Members $29.00
  • Type:
    Conference Presentation
  • Conference Type:
    AIChE Spring Meeting and Global Congress on Process Safety
  • Presentation Date:
    April 21, 2021
  • Duration:
    20 minutes
  • Skill Level:
    Intermediate
  • PDHs:
    0.50

Share This Post:

v\:* {behavior:url(#default#VML);} o\:* {behavior:url(#default#VML);} w\:* {behavior:url(#default#VML);} .shape {behavior:url(#default#VML);}

Pelin Döloðlu Normal Pelin Döloðlu 2 247 2020-11-20T13:26:00Z 2020-11-20T13:26:00Z 1 306 1749 en-US 14 4 2051 16.00 16.0000 0 0 0 0 0 True c490a67c-dea0-4aaa-ae0f-f99bae3aceb9 10042@tupras.com.tr 2020-11-20T12:17:56.6696811Z Genel Microsoft Azure Information Protection d3ce1a02-ced0-4abc-9ddd-94228945f9a4 Manual Genel

false 21 false false false TR


/* Style Definitions */ table.MsoNormalTable {mso-style-name:"Table Normal"; mso-tstyle-rowband-size:0; mso-tstyle-colband-size:0; mso-style-noshow:yes; mso-style-priority:99; mso-style-parent:""; mso-padding-alt:0cm 5.4pt 0cm 5.4pt; mso-para-margin:0cm; mso-para-margin-bottom:.0001pt; mso-pagination:widow-orphan; mso-hyphenate:none; font-size:10.0pt; mso-bidi-font-size:11.0pt; font-family:"Calibri",sans-serif; mso-ascii-font-family:Calibri; mso-ascii-theme-font:minor-latin; mso-hansi-font-family:Calibri; mso-hansi-theme-font:minor-latin; mso-bidi-font-family:Calibri; mso-bidi-theme-font:minor-bidi; mso-ansi-language:TR;}


line-height:107%;font-family:" times new roman>The petroleum facilities
require large amount of water for the cooling, boiler feed, processing,
sanitary services, fire protection, and many other miscellaneous purposes. Both
feed water and resultant water in the refineries must be well treated due to
corrosive effect, quality requirements and environmental issues. Treating the
water via reverse osmosis (RO) membranes is an important industrial process in
terms of sustainability ([1]). This study focuses on the data driven modeling
of an industrial Reverse Osmosis Membrane Unit (ROMU) which includes cartridge
filters, high pressure pump, and RO membrane series. RO membranes are composed
of two stages with 36 and 18 membranes respectively. In more detail, one
membrane module contains 6 spiral wound polyamide membranes as shown in Fig. 1.



normal">Figure
1.

Simplified ROMU diagram

line-height:107%;font-family:" times new roman>Despite their wide usage,
RO membranes suffer from permanent fouling once they are not maintained
properly, resulting in higher cost and reduced product amount ([2]). In
addition, the actual nature of the process is complex with high number of
non-linearly coupled process variables. RO membrane fouling modeling and the
determination of the major impacts on the process are the primary objectives of
this study. Artificial Neural Network (ANN) is trained for the identification
of the process to infer the impact of the plant and feed parameters on the
outputs, primarily the product rate. The data for the model development contain
the last 4 years, since the installation of the plant to date. The data include
all sensors related to pressure, flow, temperature, conductivity, and pH.  Next, the ANN is evaluated at probable
operating conditions to calculate the operating window of the plant. The
results show the impact of the process parameters on the product rate.

" times new roman>

References

" times new roman>[1] Ismail, F., Khulbe, K. C., & Matsuura, T.
(2018). Reverse Osmosis. Elsevier.

" times new roman>[2] Kang, G. D., & Cao, Y. M. (2012). Development
of antifouling reverse osmosis membranes for water treatment: a review. Water
research
46(3), 584-600.
