Scale-up of SAPO-34 Membranes for CO2/CH4 Separation

Developed by: AIChE
  • Type:
    Conference Presentation
  • Conference Type:
    AIChE Annual Meeting
  • Presentation Date:
    October 29, 2012
  • Duration:
    30 minutes
  • Skill Level:
  • PDHs:

Share This Post:

Once the content has been viewed and you have attested to it, you will be able to download and print a certificate for PDH credits. If you have already viewed this content, please click here to login.
SAPO-34 membranes have pores with a diameter of approximately 0.38 nm and have the potential to be used for large scale removal of CO2 impurities from natural gas. Tubular SAPO-34 membranes have been shown previously to have high permeances and selectivities at high pressures, so that CO2 can be removed while maintaining CH4 at high pressures. Here we show that the SAPO-34 membrane preparation can be scaled up and simplified. The membranes were prepared on 7-channel monolith alumina supports to increase the membrane surface area per volume.

The SAPO-34 separation layers were grown on both single-channel and monolith supports using seeded synthesis where the SAPO-34 seeds were deposited on the supports either by dip-coating, rub-coating, or a newly developed seeding technique. The membranes prepared on monolith supports had average CO2 permeances of 6.3 x 10-7 +/- 0.9 mol/(m2sPa) and average selectivities of 56 +/- 4 for 50/50 CO2/CH4 mixtures at 46 bar feed pressure. These permeances and selectivities were probably limited by concentration polarization because the available mass flow controllers limited the maximum feed rate and resulted in high stage cuts when the seven-channel monoliths were used. Analysis of the monolith membranes by SEM indicate that the SAPO-34 layers were a few µm thick, and they were slightly thinner than SAPO-34 membranes prepared on single channel tubes.
