In Operando Study of All-Solid-State Lithium Batteries Coupling Thioantimonate Superionic Conductors with Metal Sulfide

Source: AIChE
  • Type:
    Conference Presentation
  • Checkout

    Checkout

    Do you already own this?

    Pricing


    Individuals

    AIChE Member Credits 0.5
    AIChE Members $19.00
    AIChE Graduate Student Members Free
    AIChE Undergraduate Student Members Free
    Non-Members $29.00
  • Conference Type:
    AIChE Annual Meeting
  • Presentation Date:
    November 10, 2021
  • Duration:
    25 minutes
  • Skill Level:
    Intermediate
  • PDHs:
    0.50

Share This Post:

All Solid-state Lithium metal batteries (ASLBs) are considered as next generation energy storage devices to deliver high energy density and safety. The intrinsic nonflammability of solid-state electrolytes (SEs) can significantly improve the battery safety by reducing fire risk. Among various SEs candidates, sulfide SEs have ultrahigh ionic conductivity and low mechanical stiffness. However, sulfide SEs suffer from poor compatibility with the conventional transition metal oxide electrodes due to narrow electrochemical stability window and poor chemical stability. Therefore, it is crucial to pair sulfide electrolytes with the proper cathode in developing stable ASLBs.

In this work, we synthesized and systematically studied one type of thioantimonate ion conductor, Li6+xGexSb1-xS5I, with different compositions, where Li6.6Ge0.6Sb0.4S5I exhibits highest ionic conductivity of 1.6 mS cm-1 at room temperature. A metal sulfide FeS2 cathode which owns high specific capacity and excellent chemical compatibility with sulfide electrolytes was chosen to couple with Li6.6Ge0.6Sb0.4S5I in ASLBs without additional interface engineering. For the first time, in situ energy dispersive X-ray diffraction (EDXRD) was applied in the study of ASLBs without disassembling the sealed cells or special cell designing to characterize the structural stability of the Li6.6Ge0.6Sb0.4S5I and FeS2 during cycling. EDXRD in situ observed the decomposition of Li6.6Ge0.6Sb0.4S5I at low voltage which confirms the safe operation voltage range. The electrochemical stability was investigated, and a safe operating voltage window ranging from 0.7~2.4 V (vs. In-Li) was achieved. Compared with fast-decaying performance in liquid electrolyte batteries, the SEs can effectively confine Fe0 aggregation and polysulfide shuttle effect in the ASLBs. The ASLBs paring FeS2 cathode and Li6.6Ge0.6Sb0.4S5I electrolyte delivers a high initial capacity of 715 mAh g-1 at C/10 which keeps stable for 220 cycles with a high-capacity retention of 84.5%. As a result of excellent compatibility between FeS2 and Li6.6Ge0.6Sb0.4S5I, outstanding capacity and cycling stability are achieved at the same time.

Presenter(s):
