Milking Lipids From Green Alga: Feasibility of Using Biocompatible Solvents to Extract Lipids From Living Cells

  • Type:
    Conference Presentation
  • Conference Type:
    AIChE Annual Meeting
  • Presentation Date:
    October 17, 2011
  • Skill Level:
  • PDHs:

Share This Post:

A key hurdle in realizing commercial-scale production of biodiesel from cultured algae is efficient harvesting/dewatering of algal cells. In order to produce a gallon of biodiesel from algae, thousands of gallons of water must be processed, even when algal biomass is grown in relatively concentrated suspensions. For example, a recent study1 using an outdoor raceway pond grew algae at 2.8 g/L (11% lipid content), which would require that at least ~3,000 gal of water be processed to produce 1 gallon of biodiesel.

A proposed alternative to growth and subsequent dewatering methods is milking of cells: a process that continually extracts lipids without sacrificing the cells. The method combines growth and extraction by contacting cells with a biocompatible solvent. Because cells can be maintained in the stationary growth phase with balanced growth under nutrient limitation, it is hypothesized that the supply of essential compounds for photosynthesis (CO2, H2O, and light) would be directed more toward excess carbon storage in the form of lipids rather than new cellular growth. Ideally, external nutrients, nitrogen and phosphorus, would be internally recycled during balanced growth, thus avoiding the need for expensive fertilizers to be added. Previous studies2,3 have used n-dodecane as a biocompatible solvent for b-carotene extraction from the alga Dunaliella salina. Our work tests the feasibility of this solvent for milking lipids from two green alga strains - Ankistrodesmus falcatus and Chlorella klebsiella.

Batch studies were performed to identify biocompatible solvents for algae, which also facilitate extraction of intercellular compounds. Small culture volumes (90 mL in triplicate) were continuously mixed with 12% (v/v) of n-dodecane for 4 days. Cell viability was assessed each day by growth rate determinations and total and dead cell counts. Ankistrodesmus maintained a population of live cells (the difference between total and dead cells) during exposure to solvent. Mean growth rates in Chlorella remained positive after solvent exposure. These results indicated that n-dodecane was biocompatible with both alga strains for the duration of the batch experiments.

More recently, bioreactor experiments are being performed during which the growth of cells and continuous production of lipids are being monitored in four 2-L bioreactors. Each bioreactor has an increasing rate of contact between the algal suspension and dodecane phase through a static mixer external to the reactor volume. Nitrogen-limited cultures were provided CO2, light, and distilled make-up water (from evaporation); no additional nutrients were provided. Results will be presented for a series of experiments of four-week duration highlighting (1) the ongoing viability of cells when exposed to solvent; (2) the retention and recycling of nutrients in the algal suspension; and (3) extraction of lipids to the solvent phase.


1. da Silva TL, Reis A, Medeiros R, Oliveira AC, Gouveia L: Oil Production Towards Biofuel from Autotrophic Microalgae Semicontinuous Cultivations Monitorized by Flow Cytometry. Appl Biochem Biotechnol 2009, 159(2):568-578.

2. Hejazi MA, de Lamarliere C, Rocha JMS, Vermue M, Tramper J, Wijffels RH: Selective extraction of carotenoids from the microalga Dunaliella salina with retention of viability. Biotechnol Bioeng 2002, 79(1):29-36.

3. Hejazi MA, Holwerda E, Wijffels RH: Milking microalga Dunaliella salina for beta-carotene production in two-phase bioreactors. Biotechnol Bioeng 2004, 85(5):475-481.
