Inferential Monitoring & Optimization of Crude Units Via Hybrid Models

Developed by: AIChE
  • Type:
    Conference Presentation
  • Conference Type:
    AIChE Spring Meeting and Global Congress on Process Safety
  • Presentation Date:
    March 15, 2011
  • Skill Level:
  • PDHs:

Share This Post:

Once the content has been viewed and you have attested to it, you will be able to download and print a certificate for PDH credits. If you have already viewed this content, please click here to login.

Refinery crude units often process variety of feedstocks. If properties of the feed entering the crude unit are not precisely known, it is difficult to predict how changes in the tower operating conditions will affect properties of the products. Similarly, if on-line analyzers are not available, it is not possible to implement very accurate control of the product properties.

This work introduces a new class of models (hybrid models) which can be used to: (i) identify feed distillation curve, (ii) predict product properties from tower operating conditions, and (iii) predict product properties from feed properties and material and energy balances. Hybrid models consist of first principles equations (e.g. balances) and of Partial Least Squares (PLS) models for prediction of product or feed properties. A model of a crude unit has several hundred equations and is practically linear; this model predicts target properties within 1% of the rigorous tray to tray model which consists of 10k-20k nonlinear equations.

In industrial practice there is a very limited number of tray temperature measurements; the models we have developed enable us to achieve the accuracy of prediction that is the same as if there are tray temperature measurements available on every tray. In addition, inclusion of material and energy balances in the hybrid model equations enables optimization of tower operating conditions based on the hybrid model.

We present results of a) optimization of tower operating conditions based on the hybrid model and based on the equation-oriented AspenPlus model; b) identification of the crude feed distillation curve based on the limited number of tray temepratures and the hybrid model variables and compare it to predictions one would obtain if there were tray temperatures available on every tray; c) prediction of product properties from the available tray temperatures and hybrid model variables.

Accuracy of the hybrid model predictions and almost linear nature of its equations makes it suitable for applications in on-line monitoring, or as inferential predictor for model-based controllers, or for optimization of operating conditions, or for crude unit modeling in the refienry plannign and scheduling tools.
