Dynamic Modeling and Application of Model Predictive Control to the Cool-Down Process of a Liquefied Natural Gas (LNG) Tank

  • Checkout

    Checkout

    Do you already own this?

    Pricing


    Individuals

    AIChE Member Credits 0.5
    AIChE Members $19.00
    AIChE Graduate Student Members Free
    AIChE Undergraduate Student Members Free
    Non-Members $29.00
  • Type:
    Conference Presentation
  • Conference Type:
    AIChE Annual Meeting
  • Presentation Date:
    November 7, 2021
  • Duration:
    19 minutes
  • Skill Level:
    Intermediate
  • PDHs:
    0.50

Share This Post:

Liquefied natural gas (LNG) is a natural gas which is liquefied below its boiling point (-160 C) and has been widely adopted as an alternative to conventional petroleum energy sources to comply with the tightening environmental regulations [1]. During the loading of LNG, excessive boil-off gas (BOG) is unavoidable due to the large temperature difference between the LNG and a tank, and this causes a pressure change in the tank [1, 2]. In addition, the drastic change of the temperature inside the tank induces the thermal stress of a tank material, which may cause potential damage to a tank structure [3]. In order to prevent the aforementioned issues, it is necessary to gradually decrease the temperature of the tank before loading the LNG into a cargo containment system, which is known as a pre-cooling or cool-down process [4].

During the cool-down process, the injection of a large amount of LNG spray into the tank ensures rapid temperature reduction of the tank while resulting in high thermal stress of a tank wall [5]. Meanwhile, the LNG spray also produces excessive BOG, which continuously builds up pressure inside the tank. Hence, to ensure the safety of the tank, vent gas is released from the tank to regulate the elevated pressure. However, the vent gas requires further treatment, such as reliquefaction, to return it to the cargo tank, which increases energy costs [6]. In this regard, it is important to effectively adjust the manipulated variables such as the amount of LNG spray and vent gas to achieve safe and economic operation of the cool-down process.

Model predictive control (MPC) has been widely implemented in industrial applications due to its ability to handle constrained multi-input-multi-output problems [7]. For instance, the MPC has been applied to the LNG tank system and proven to perform better than conventional PI control for set-point tracking and disturbance rejection [8]. Moreover, it has been reported that the MPC scheme efficiently controls the tank pressure [9]. Although the MPC control techniques have been developed to control the steady-state system, no studies have been carried out considering the transient cool-down process of the LNG tank.

Hence, in this work, a MPC system that can regulate the pressure and temperature of the tank was formulated and applied to the cool-down process. First, a mathematical model for the cool-down process was developed, and subsequently, a reduced-order model (ROM) was proposed using the N4SID algorithm [10]. The developed model was then utilized in the MPC scheme to control the pressure and temperature of the tank where the manipulated variables are the flowrate of the LNG spray and the vent gas. As a result, the MPC system was able to drive the pressure and temperature to set-point values while minimizing the amount of LNG spray and the vent gas.
