Controlling the Effect of Slug-to-Slug Variation on the Crystal Size Distribution of Perovskite QDs: A CFD-Based Approach

Source: AIChE
  • Type:
    Conference Presentation
  • Checkout

    Checkout

    Do you already own this?

    Pricing


    Individuals

    AIChE Member Credits 0.5
    AIChE Members $19.00
    AIChE Graduate Student Members Free
    AIChE Undergraduate Student Members Free
    Non-Members $29.00
  • Conference Type:
    AIChE Annual Meeting
  • Presentation Date:
    November 10, 2021
  • Duration:
    21 minutes
  • Skill Level:
    Intermediate
  • PDHs:
    0.50

Share This Post:

Recently, manufacturing of metal halide perovskite quantum dots (QDs), particularly cesium lead bromide (CsPbBr3), has received substantial attention due to its superior tunable optoelectronic properties (related to their size), and because they cater to wide array of applications such as solar cells, next generation displays, and LEDs. [1] Thus, it is of paramount importance to develop a manufacturing route which results in controlled size and size distribution with a desired surface passivation of CsPbBr3 QDs for the targeted application in photonic and optoelectronic devices. Furthermore, device-level applications demand a fast and large scale production of application-ready QDs. However, the large-scale production of these QDs has posed certain engineering and practical challenges. Specifically, an absence of a well-established crystallization model, lack of batch-to-continuous scale-up studies, and unavailability of set-point tracking platforms are the major roadblocks. [2] The fact that slug flow crystallizers (SFCs) offer a large operation range (i.e., precursor concentration, gas-liquid flow rates) has inspired recent studies on proposing SFCs for large scale continuous manufacturing of metal halide perovskite QDs. [3]

Despite the intriguing advantages of SFCs, there are still some key issues with the operation of SFCs. For example, previous studies have not accounted for the effect of slug-to-slug (S2S) variation on crystal size distribution (CSD), and the absence of a modeling and control framework for CsPbBr3 QDs made it challenging to fine-tune the QD size distribution. [4] In response, we have developed a computational fluid dynamics (CFD) model to elucidate the mechanism of slug formation process in a millifluidic SFC, and then combined it with a slug crystallizer model to accurately model QD size distributions and precursor concentration profiles in SFC. Specifically, the slug crystallizer model was constructed by combining a continuum model with a previously developed kinetic Monte Carlo (kMC) model. [5] Based on the CFD-based multiscale modeling framework (i.e., CFD + continuum + kMC model), an optimal operation problem was formulated to ensure adequate set-point (QD size) tracking, resulting in a narrow CSD. Overall, (a) the proposed multiscale model is in good agreement with the experimental results; (b) the CFD simulation highlights the region in which the SFC should be operated (i.e., stable slug flow regime); and (c) the optimizer is capable of effective simultaneous set-point tracking (QD size) and disturbance rejection (S2S variation) while ensuring a narrow CSD.

In summary, the CFD model was used to identify a stable slug regime and quantify the S2S variation in a millifluidic SFC. Additionally, a dynamic multiscale model for a SFC was developed to describe the temporal evolution of average QD size and CSD. Lastly, an optimization-driven controller scheme was implemented to ensure that the QDs match the industry specifications while maintaining a narrow CSD. Overall, the proposed work is a major leap towards continuous nano-manufacturing of metal halide perovskite QDs, which will be crucial in meeting market demands of the optoelectronics industry in the coming decade.

Literature Cited:

  1. Protesescu L, Yakunin S, Bodnarchuk MI, Krieg F, Caputo R, Hendon CH, Yang RX, Walsh A, Kovalenko MV. Nanocrystals of cesium lead halide perovskites (CsPbX3, X= Cl, Br, and I): novel optoelectronic materials showing bright emission with a wide color gamut. Nano Letters. 2015 Jun 10; 15(6):3692-6.
  2. Pu Y, Cai F, Wang D, Wang JX, Chen JF. Colloidal synthesis of semiconductor quantum dots toward large-scale production: a review. Industrial & Engineering Chemistry Research. 2018 Feb 14; 57(6):1790-802.
  3. Abdel‐Latif K, Epps RW, Kerr CB, Papa CM, Castellano FN, Abolhasani M. Facile room‐temperature anion exchange reactions of inorganic perovskite quantum dots enabled by a modular microfluidic platform. Advanced Functional Materials. 2019 Jun; 29(23):1900712.
  4. Rasche ML, Jiang M, Braatz RD. Mathematical modeling and optimal design of multi-stage slug-flow crystallization. Computers & Chemical Engineering. 2016 Dec 5; 95:240-8.
  5. Sitapure N, Epps R, Abolhasani M, Kwon JS. Multiscale modeling and optimal operation of millifluidic synthesis of perovskite quantum dots: towards size-controlled continuous manufacturing. Chemical Engineering Journal. 2020 Dec 7:127905.
