Assuring Ethylene Purity: Reliable Ppm and Ppb Measurement of Acetylene with Online TDL Analyzers

Developed by: AIChE
  • Type:
    Conference Presentation
  • Conference Type:
    AIChE Spring Meeting and Global Congress on Process Safety
  • Presentation Date:
    April 30, 2013
  • Duration:
    15 minutes
  • Skill Level:
  • PDHs:

Share This Post:

You will be able to download and print a certificate for PDH credits once the content has been viewed. If you have already viewed this content, please click here to login.

Real-time measurement of certain trace gas species during ethylene production is critically important for optimized production and quality control. Trace gas species such as ammonia (NH3), moisture (H2O) and acetylene (C2H2) need to be maintained at appropriate concentration levels to achieve optimum catalytic efficiency, catalyst life time and reactor throughput without compromising product purity for polymerization processes. This requires accurate monitoring of these trace gases at various stages of the ethylene production process.

Conventional detection of acetylene primarily relies upon gas chromatograph (GC), which comes with a high cost of ownership, high requirements for operator expertise, intensive maintenance and slow (several minutes) measurement response times. This paper will introduce TDL analyzers SpectraSensors developed for C2H2 measurements in various stages of the ethylene production process. This paper will describe system design and present both lab experiment and field operation data for C2H2 measurements in the range of 0-10 ppm­v, 0-100 ppmv and 0-5000 ppmv.  Employing 2nd-harmonic (2f) spectroscopy, multipass Herriott cells, advanced spectroscopy analysis algorithms, a fast Reduced Instruction Set Computer (RISC) and compact modular sample handling systems, these analyzers have demonstrated fast response time (in seconds), superior detection sensitivity and reading repeatability. The analyzers achieved 3σ repeatability of better than ±50ppbv for 0-10 ppm­v measurement range, better than +/- 2% of full scale for 0-100 ppmv and 0-5000 ppmv ranges.
