Improved Estimation of Constant Relative Volatilities to Identify Energy-Efficient Heat-Integrated Distillation Configurations

Source: AIChE
  • Checkout

    Checkout

    Do you already own this?

    Pricing


    Individuals

    AIChE Member Credits 0.5
    AIChE Members $19.00
    AIChE Graduate Student Members Free
    AIChE Undergraduate Student Members Free
    Non-Members $29.00
  • Type:
    Conference Presentation
  • Conference Type:
    AIChE Spring Meeting and Global Congress on Process Safety
  • Presentation Date:
    April 20, 2021
  • Duration:
    30 minutes
  • Skill Level:
    Intermediate
  • PDHs:
    0.50

Share This Post:

When performing a multicomponent separation, the search space of distillation configurations is vast [1]. Although well-established commercial process simulators can be used to analyze each configuration, this is a tedious and time-consuming task. Hence, industrial practitioners often rely on heuristics and past experience when choosing a configuration. An alternative methodology, which is faster than performing detailed simulations and can yield more attractive configurations than heuristics, is to utilize shortcut methods [2]. Shortcut methods can be employed within an optimization formulation in order to systematically comb through the numerous configurations and quickly identify a handful of attractive candidates.

One of the challenges during the optimization of a distillation configuration is the complex and inter-connected vapor-liquid equilibrium (VLE) equations. Shortcut methods (such as the classical Underwood and Fenske methods) often assume constant relative volatilities to overcome this computational challenge. However, relative volatilities can vary widely for a multicomponent mixture. Building upon prior works [3,4], we propose a three-step parameter estimation approach to determine the best set of values for this assumption [5]. The key insight is to treat relative volatility as a mathematical parameter, whose value is to be determined by fitting so that the surrogate VLE is as close as possible to the true VLE. We demonstrate that this approach generates relative volatilities that can effectively capture the true VLE for a four-component paraffins mixture.

To separate this mixture, we identify energy-efficient distillation configurations which utilize heat integration, by using the generated relative volatilities in an optimization formulation that we developed. During the modelling of heat integration, feasibility of heat transfer must be checked, and is traditionally performed by comparing temperatures. However, temperatures are costly to calculate during optimization. Taking advantage of the constant values of relative volatilities in our formulation, we develop shortcut criteria to check for feasibility of heat transfer in a manner that is computationally cheaper than the use of temperatures.

  1. Shah, V. H., & Agrawal, R. (2010). A Matrix Method for Multicomponent Distillation Sequences. AIChE Journal, 56(7), 1759–1775.
  2. Madenoor Ramapriya, G., Selvarajah, A., Jimenez Cucaita, L. E., Huff, J., Tawarmalani, M., & Agrawal, R. (2018). Short-Cut Methods versus Rigorous Methods for Performance-Evaluation of Distillation Configurations. Industrial & Engineering Chemistry Research, 57(22), 7726–7731.
  3. Anderson, N. J., & Doherty, M. F. (1984). An Approximate Model for Binary Azeotropic Distillation Design. Chemical Engineering Science, 39(1), 11-19.
  4. Tumbalam Gooty, R., Mathew, T. J., Tawarmalani, M., & Agrawal, R. An MINLP Formulation for Identification of Thermodynamically-efficient Multicomponent Distillation Configurations. In Preparation.
  5. Mathew, T. J., Tumbalam Gooty, R., Tawarmalani, M., & Agrawal, R. Quickly Assess Distillation Columns. Accepted.
