Balancing Act - Simple Techniques for Steam Header Controls

Developed by: AIChE
  • Type:
    Conference Presentation
  • Conference Type:
    AIChE Spring Meeting and Global Congress on Process Safety
  • Presentation Date:
    April 30, 2013
  • Duration:
    30 minutes
  • Skill Level:
  • PDHs:

Share This Post:

Once the content has been viewed and you have attested to it, you will be able to download and print a certificate for PDH credits. If you have already viewed this content, please click here to login.

An industrial steam distribution system with multiple headers, turbines, boilers, and reducing valves is managed with header control strategies that mitigate upsets, increase power generation, and reduce clean condensate makeup. Effective use of override, anti-windup, and TG governor interface strategies insure header stability. Upsets are managed without cascading into multiple equipment failure. An overall coordination scheme is built from optimum use of pressure reducing valves that is easily grasped by operating personnel.

Coordinating interconnected steam headers is impossible without automatic control. A major upset on one header can cascade throughout the system causing multiple equipment failures and eventual plant outage. A control strategy that coordinates turbines, boilers, and reducing valves can balance a multiple header system during normal operation and prevent a catastrophic failure during a major upset.

 Coordinated control of the pressure reducing valves (PRVs) is the most effective too for stable header control.  Proper configuration of override controls and limiters keep the valves closed until needed.  Interfaces with the Woodward TG governor systems coordinate the PRVs with TG extraction to allow PRVs to take over when the TGs are unavailable.
